    Sunflower Seed Industrial Bucket Lift Elevator Medicine Building Grading

    Ask Lasest Price
    Brand Name : Tongxin
    Model Number : TD
    Certification : CE
    Price : Negotiate
    Payment Terms : L/C, D/A, D/P, T/T, Western Union, MoneyGram
    Supply Ability : 1000 sets/month
    Delivery Time : According to the order quantity
    • Product Details
    • Company Profile

    Sunflower Seed Industrial Bucket Lift Elevator Medicine Building Grading


    Sunflower Seed Industrial Bucket Elevators Medicine Building Size Grading


    Product Description


    The bucket elevator is a product that has been introduced and developed by foreign advanced technology. It is suitable for vertical conveying of powdery, granular and massive materials, as well as materials with greater abrasiveness, such as fly ash, slag, limestone, cement raw material, cement clinker, cement, coal, dry clay, etc.

    The temperature of the material generally does not exceed 250 degrees and the lifting height is up to 40 meters.

    Features

    1. The high efficiency vertical bucket elevator for sale in China is in good sealing, little environmental pollution.

    2. The high efficiency vertical bucket elevator for sale in China operation is satisfactory reliability, lift high altitude.

    3. Low power required(effective inflow feeding,induction material handling).

    4. The high efficiency vertical bucket elevator for sale in China is much reliable in quality.


    Applicable Fields of Belt Conveyor



    The bucket elevator is used for powder, granule, block material vertical continuous rising. Widely applied in the feed mills,grain and oil plant,food,chemical, Building materials, grain store, bulk materials' lifting transport in port.

    Working Principle


    Gas purification processGas with dust get into filter chamber through air inlet. Coarse dust particles due to inertial impaction, natural sedimentation and dust box, fine dust rose into the air with each filter chamber under negative pressure of the wind, the outer barrier attached to the bag and was purified gas from the outlet discharge.
    Soot cleaning processIssued by the electronic control system control signals, by incorporating gas system to complete, due to the use of sub-chamber structure, by-room cleaning, so much so that dust is always in the room to work, room cleaning status guarantees a filtration resistance stability.


    Technical Parameters


    Hoist ModelTD250TD315TD400TD500TD630TD800TD1000
    Hopper TypeJT
    Transportation Quantitym³/h15-2532-4650-7584-120135-190216-310340-480

    Hopper

    Bucket Widthmm2503154005006308001000
    Bucket CapacityL36122550100200
    Bucket Pitchmm200200250320400500630

    Chain

    Pitchmm100100125160200250315
    Chain No.12
    Chain Capacity(min)kn112/160160/224224/315315/450450/630630/990
    Chain Wheel Diammm386.37386.37482.96618.19772.74965.921217.06
    Spindlemm24.7124.7119.7815.4513.269.897.85


    Note: this is only for reference and products specification should be studied from the real products provided. Can be customized according to customer requirements.

    Our Service


    1. We Provide video installation instructions;
    2. We offer 24-hour online consulting service;
    3. 20 years production experience to ensure quality;
    4. We have thorough data to ensure the quality;
    5. We provide detailed instruction an product information.

    If you want to get more information of product, please contact us!
